Technical Parameters:
Item | Ordinary Type | Extra-Long Type | Wide Body Extra-Long Type |
|---|---|---|---|
max. Working Presure | 57Mpa | ||
Max. Rail Pulling Force | 2×450KN | ||
Cylinder Working Stroke | 760mm | ||
Draw Bar Center Distance | 360mm | 610mm | |
Lock Mode | iron wedge web clamping | ||
Machine Weight | ≤300g | ≤370kg | ≤530 kg |
Petrol Pump Station(optional) | Honda GX160 petrol engine
power3.05kw、flow ≥3L/min、weight75kg
| ||
Electric Pump Station(optional) | power3kw、voltage380V、flow≥3L/min、weight85kg | ||
