Technical Parameters:
Parameter | Unit | Value |
|---|---|---|
Rated Lifting Force | kN | 150 × 2 |
Lifting Cylinder Stroke | mm | 800 |
Rated Channel Dialing Force | kN | 200 |
Dialing Volume | mm/time | ≥150 |
Operating Pressure of the System | MPa | 16 |
Operating Force of Manual Pump | N | 350 |
Engine Power | kW | 9.5 |
Volume (L×W×H) | mm | 1750 × 850 × 1510 |
Quality | kg | 588 |
