Technical Parameters:
Parameter | Unit | Value |
|---|---|---|
Welder Main Power Supply Rated Voltage (Grid Electricity) | V | 380 |
Welder Main Power Supply Rated Voltage (Generator Set) | V | 400 |
Welding Main Circuit Phase Number | 2 | |
Welder Control System Main Power Supply Phase Number | 3 | |
Power Supply Rated Frequency | Hz | 50 |
Primary Circuit Rated Current (Duty Cycle 50%) | A | 600 |
Welding Main Circuit Rated Power | KVA | 240 |
Max. Welder Control and Lifting System Power | KVA | 50 |
Hydraulic System Max. Working Pressure | MPa | 20 |
Max. Upsetting Force | KN | 1200 |
Max. Clamping Force | KN | 2900 |
Welding Dynamic Frame Max. Stroke | mm | 120 |
Welding Max. Stroke (At Upsetting Quantity 15mm) | mm | 80 |
Welder Head Weight | Kg | 4000 |
Max. Welding Efficiency | Number Per Hour | 12-16 |
Suitable For Rail Type | 38,43,50,60,75 and All Series of Rails | |
