Technical Parameters:
- YCD - 32 Hydraulic switch tamper- No hydraulic motors
- Internal combustion engine power 9.5kw (Honda GX390)
- Vibration frequency: 66.7hz
- Exciting force of 31.5kn
- Oil pressure of the operating system is 4 ~ 5MPa
- Ramming pick and inserting depth under pillow 90-100mm
- The mass of the main engine is 436kg
- External dimension: 1430mm×930mm×1700mm
- Production efficiency: 30min/ group of switches/group of machines
